1-1/8" Crows Foot Wrench for JL Billet AR-15 Barrel Nuts
This 1-1/8" crows foot is made to fit our proprietary AR-15 / 5.56 barrel nuts. If you are installing a JL Billet 5.56 free float handguard, it lets you torque the barrel nut to spec with a standard 3/8" drive torque wrench, without breaking the bank.
Each crows foot is precision CNC machined from 4130 chromoly for superior strength and finished in black nitride for corrosion resistance.
Specifications
- Opening: 1-1/8"
- Drive: 3/8" square drive
- Material: 4130 chromoly steel
- Finish: Black nitride
- Fits: JL Billet AR-15 / 5.56 barrel nuts
- Construction: Precision CNC machined
- SKU: JLB-CF-1125
Installation Tip
Mount the crows foot at 90° to the torque wrench handle. At that angle the effective length of the wrench does not change, so the torque reading stays accurate.
Which JL Billet Crows Foot Do I Need?
- 1-1/8" chromoly (this tool): JL Billet AR-15 / 5.56 barrel nuts, like our AR-15 barrel nut (1.375" OD)
- 1.2" Adams Arms crows foot: JL Billet Adams Arms compatible barrel nuts
- 1-5/16" chromoly crows foot: current JL Billet .308 handguards, including the MLA and ULA M-Lok series
- 1-1/8" Gen II crows foot: JL Billet .308 Gen II barrel nuts
Not sure which barrel nut you have? Contact us with your handguard model and we'll point you to the right wrench. Shop all armorer's tools.
